DT Swiss HXC1501 29 Centre Lock 15/110 30wd Carbon Disc E-Bike Front Wheel
Built to extend your eMTB adventures - a carbon wheelset with high-end technology.
This Hybrid wheelset was made for riders who are looking for the ultimate performance an eMTB wheelset can offer. Now with a carbon rim, the HXC 1501 SPLINE ONE becomes the high-end Hybrid MTB wheelset in the DT Swiss portfolio. The carbon rim is combined with a redesigned hub shell, offering better drive and brake moment resistance, which occurs from the bigger motors and the heavier eMTBs. With the new Ratchet EXP OS system with 30 teeth, the torque developed by the motor and the rider is transmitted directly from the pedals to the ground. This transfer is enabled through reinforced spokes for even sharper accelerations than the previous Hybrid range. Every component has been thought out, developed and tested to ensure a fun, stress-free ride at all levels.
| Rim Height | 25 mm |
| Rim Diameter | 622 mm (29" / 700C) |
| Inner Width | 30 mm |
| Tyre Interface | Hookless tubeless TSS |
| Valve Hole | Presta |
| Brake Interface | Disc Center Lock |
| Axle System | 15 mm Thru axle |
| Built-in Dimension | 110 mm Boost |
| Cassette Interface | - |
| Freehub Body | - |
| Freehub System | - |
| Included | Tubeless tape 32 mm TL valve alu black 18-25 mm |
| Recommended for E-Bikes | Yes (max. 32Km/h or max. 250W) |
| Net Weight (g) | 869 |
