Shimamo's Steps E6002 Drive Unit features a 250 watt nominal output, walk assist mode, and Symphomaticautomatic shifting when paired with a Shimano DI2 internal gear hub. It is compatible with all brake types.
Technologies
E-Tube - Is Shimano's "service" that uses websites or apps to maximise the enjoyment of riding a bicycle by connecting the riders, the bicycles and Shimano.
Features
Easy to access -Improved feature for "quick walk assist" function
New lighting system -Brighter front and rear lighting system with a supplied 2 Amp fuse
Quick and easy assembly -Connect directly with lighting system without using SM-DUE01. Reduce firmware update time down to 12 seconds
Compatibility -Light off-road program compatible with internal geared hub system. MTB DI2 rear derailleur specification available.
Specifications
Colour Black/Grey Average Weight 3.1kg Remarks Set by E-TUBE PROJECT. ** By using SM-DUE10/SM-DUE11 Compatible Brake type V-BRAKE, Roller brake, Disc brake Motor Type Brushless motor Position Mid Ship Compatible Wheel Size *1,300 - 2,400mm Continuous Rated Power 250W Maximum torque 50Nm Rated Voltage DC 36 V Power supply for front light DC 6 V Power supply for rear light DC 6 V Communication E-Tube Compatible bottom bracket type Square Type E-tube connect 0 pcs E-tube port 2 pcs Maximum current supply front and rear light total 2A Port for Speed Sensor (pcs) - SD50 type 1 pcs Port for Light 0 pcs Terminal for Light 1 pcs
